Low Pressure oil-free screw air compressor Made In China 160KW

Main uses and guarantees:

Energy saving: energy saving more than 15% compared with dry oil-free compressor.
Environment protection: no using any lubricate oil to avoid environment pollution.
Reliability: absolutely guarantee oil-free.

Because the purified water takes part into the compressing process to seal, cool and lubricate, it increases efficiency. With the same motor power, comparing with dry oil-free air compress, there is 15% more air production of oil-free screw air compressor of water lubrication, it reduces the energy consumption greatly. The consumption material of oil-free screw air compressor is only water, air filter and water filter, the maintenance cost is very low.

100% oil-free compressed air, 100% purified compressed air, 100% no oil pollution risk.

In the process of food and drink industry, medical industry, packing industry, electronic manufacture, painting industry, powder coating industry and textile manufacturing, it must avoid any risk of oil pollution, otherwise it would cause serious consequences such as manufacture damages and stop, brand and credit losing. CMN oil-free screw air compressor takes water for lubrication, there is not any lubricate oil in the air end, and at the meantime, because the purified water clean the air, the compressor air is absolutely clear and not any pollution.

Guarantee: High precision, high wear resistance, low noise, smooth and steady, high strength

⊙ Why the oil free water spray screw technology is needed?
➤ Large capacity
➤ High exhaust pressure (single stage compression pressure up to 17 bar)
➤ High efficiency
➤ Close to isothermal compression
➤ Low noise
➤ Real oil-free stainless-steel screw rotor
➤ Self-lubricating
➤ Oil free ISO85730 level certificate
➤ Lower application costs
➤ Lower maintenance costs

⊙ The technical advantage water lubricating oil-free screw air compressors

1. With the fifth generation of oil-free screw airend technology. The compressor airend and system adopt stainless alloy, thus the technological transcendence from the copper airend to the stainless steel airend is realized.

2. Integrated design is adopted for the whole machine. There are no complex pipelines and lines, and the fault points are less and more stable.

3. Less maintenance consumables (air filter, water filter), easy maintenance, no professional staff is required to operate it, and less maintenance costs.

4. There is absolutely no oil in compressor system, without any oil pollution risk, it gives guarantee of no oil in generated compressed air.

5. Volumetric efficiency is higher based no isothermal compression. More than 15% energy is averagely saved compared with dry type two stage compression oil-free screw air compressor, more than 25% energy is averagely saved compared with the dry type one stage compression, the running temperature is less than 50℃, and there is risk of being burned.

6. Wider pressure ranges:2-40Bar.

7. The full intelligent CNC precise machining technology and the force balance of the airend running can ensure lower noise, smaller vibration, and longer service life.

8. Averagely more than 10% air delivery is generated for the same power of water lubricating screw air compressors than the same power dry oil-free screw air compressor.

9. More simple and convenient operation, PLC intelligent control is adopted. Automatic fault detection, fault warning, maintenance reminder, fault reminder, automatic protection function. It can realize 24 hours unattended and remote-control function.

10. Copressed air is cleaner through cleaned by lubrication water, it can be directly used for breathing. The dew point of saturated compressed air is lower, and the water content of compressed air is lower by more than 25% than of an ordinary dry type oil-free screw air compressor.

11. The airend patent optimized design, large rotor, low rotary speed (within 3000r/min), without gearbox, direct connection drive, it has lower rotary speed and longer life compared with dry oil-free screw air compressor (10000r/min~20000r/min).

12. The function of automatic water exchange and automatic system cleaning can be realized, and the interior of the compressor is cleaner and sanitary.

⊙rigorous manufacturing process

1.Strict process manufacturing process
Every part is strictly inspected and perfected. Every procedure from raw materials to finished parts is strictly controlled to ensure that every part achieves excellent quality. Every part is optimized to ensure more durability.

2. Super-mute design of the whole machine
The whole chassis adopts super-silent design, low speed and large air volume cooling fan, and large cooler is used to reduce air convection friction, which has excellent cooling effect.

3. Humanized Structure Design
Humanized structure design, simple installation, and follow-up maintenance more convenient, polar maintenance costs, without professional staff, users can also be self-maintenance, maintenance, easy to popularize.

4. Super Clean System and Compressed Air
Stainless steel synthetic material is used in the whole system to ensure the durability, long service life, compressed air "0" pollution, more energy-saving, stable, green and environmental protection.

⊙ Benefits of Frequency Converter

❃ Compressed air output adjusts according to demand
❃ Lower system pressure, energy saving
❃ No load-unload cycle, no power consumption
❃ Smooth start, no peak start current
❃ Greatly reduce energy consumption
